- 2006-2014 Transit TT9
Key programming:
- Virgin transponder
- Can be added keys.
- If they are deleted, it is necessary to program at least 2 keys.
- Once the transponder has been added, the remote control should work automatically.
Control programming:
- Control is synchronized manually with the following procedure.
- With the door closed and the seat belt on, insert the key into the ignition and turn it from OFF to ON 8 times within 20 seconds.
- Remove the key from the ignition.
- Press any button, in some models you will hear an acoustic signal indicating that the door has been opened. the programming mode correctly and another to indicate that the remote control was successfully programmed. On other occasions you only hear the when receiving and recording the signal from the new command.
- All commands that do not Any controls present will be erased and existing controls must be added again following the previous step.
- Turn the contact from ON to OFF and open and close the door to exit programming mode. then check the controls.
Note: In the Transit model you do not hear any acoustic signal but you can hear the central control close and open to indicate that the programming mode is open and once again to indicate that the command has been recorded correctly.
Profile: Tiber HU101
Transponder:
- Zedfull: DST 80 BIT / 63WR MODE 40
- Tango: TIRIS DST80 / 40 BIT
- Keydiy: 4D 63 / DST 40
- Handy: 4D 63 / DST 40
- VVDI: 4D+DST 40
- Clonable: YES
